Polymaker Polymaker Polymide PA6-CF 2.85mm / schwarz / 0,5kg

Polymaker Polymide PA6-CF 2.85mm / schwarz / 0,5kg

significantly improved stiffness, strength and heat resistance

PA6-CF / 1.75mm or 2.85mm / 500g and 2000g / black

PolyMideâ„¢ PA6-CF is a carbon fiber reinforced PA6 (Nylon 6) filament.
The carbon fiber reinforcement provides significantly improved stiffness, strength and heat resistance with outstanding layer adhesion.

Nylon filament, although highly tensile and resistant to abrasion, has often been overlooked in FFF/FDM 3D printing. This is because of relatively poor dimensional stability (i.e. the degree to which it retains its original dimensions under heat and humidity changes) and tendency to warp when extruded.

PolyMaker’s Warp-Free ™ technology addresses these issues by chemically controlling the microstructure and crystallization behavior of the filament when it is manufactured. As a result, all internal stress built up during 3D printing is fully released prior to solidification.

Additionally, the improved printability is achieved without sacrificing the intrinsic properties of nylon.



Recommended print settings:

  • Nozzle temperature: 280 - 300 ° C.
  • Heating bed temperature: 25 - 50 ° C (do not exceed 50 ° C)
  • Installation space temperature: 25 - 50 ° C (do not exceed 50 ° C)
  • Printing speed: 60 mm / s.
  • Fan: OFF.

PA6-CF is an abrasive filament.
We therefore recommend the use of hardened nozzles with a bore of > 0.5 mm ..



  • Material
    PolyLiteâ„¢ PA6-CF
  • Drucktemperatur
    280 - 300 ËšC
  • Heizbett
    25 - 50 ˚C (Überschreiten Sie NICHT 50 °C)
  • Druckbettbeschichtung
    Fast jede Oberfläche mit einer dünnen Schicht PVA-Kleber
  • Filament Durchmesser
    1,75mm / 2,85 mm
  • Filament Nettogewicht
    2000 g
  • Verpackungsgewicht
    2,3 kg
  • Lagerung
    trocken und kühl
  • Trocknen
    bei 80 ˚C für 12h
