BIGTREETECH HDMI5 V1.2 Touchdisplay

The BTT HDMI 5 touch display is specifically designed for 3D printer users who use Klipper.
It can be used with the Raspberry Pi 4, Manta M8P + CB1, Manta M5P + CB1, and other mini PCs.

Main features:

• HD IPS screen. The 12.7 cm/5-inch screen has a resolution of 800 x 480 pixels.
• The capacitive IPS touchscreen supports 5 touch points simultaneously.
• Plug-and-Play
• The screen can be easily connected via the HDMI port. Power is supplied via the USB-C 5V port.
• No drivers need to be installed.
• This screen is perfect for 3D printer users. It works perfectly with the Big Tree Tech Manta series motherboard plus CB1.
• Give your printing system a more seamless visual experience.
• Adjustable brightness and display direction. You can increase the brightness using the Ks1 button, decrease it using the Ks3 button, and adjust the display direction by 180° using the Ks2 button.
• Audio output: built-in audio decoder, supports 3.5mm headphone jack audio output.
• 4-pin XH2.54 breakout port. The 4-pin XH2.54 breakout port enables custom connection via the USB protocol and display-independent power supply (DC 5 V).

Further downloads at: https://github.com/bigtreetech/BIGTREETECH-TouchScreenHardware

The BIGTREETECH HDMI5 V1.2 version primarily features an optimized PCB layout, including adjustments to connector orientation and the hardware's rear side.

In terms of technical specifications (such as the 800x480 pixel resolution), they are otherwise identical.

• V1.1: The HDMI and USB-C cable connectors extend from the side of the housing or PCB.
• V1.2: The connectors have been repositioned to face directly towards the rear.
  This allows for much cleaner cable management when installing the unit in 3D printer enclosures (such as those for the Voron).
